ANSI
/ NEMA FB 1 IP 54 CONDULET
CAST IRON HOT - DIP GALVANIZED
CONDUIT OUTLET BODIES
:: OC , OT , LL , LB
Application :
Conduit outlet bodies
are installed in conduit
Systems to :
# act as pull outlets
for conductors being installed
# provide openings for making splices and
taps in conductors
# act as mounting outlets for lighting fixtures
and wiring devices
# connect conduit sections
# provide taps for branch conduit runs
# make 90 bends in conduit runs
# provide for access to conductors for maintenance
and future system changes
Features :
Conduit Outlet Bodies
# Many shapes and
sizes are available for RSC , IMC , EMT
conduit see listings on right hand side
# Conduit hubs have tapered threads and
feature integral bushings for protection
of wire insulation.
Gaskets :
Solid gaskets :
# are used with blank
covers
# can be converted to open type gaskets
by tearing out center section along scored
lines - 1/2 " to 4 "
sizes
Blank Covers :
self - retaining cover
screws
Standard Materials
: Bodies -
cast iron , Cover - cast iron
Standard Finishes
: Hot - dip
galvanized and enamel clear coat , Powder
coat : information available on request
|
|
|
ABSO CONDUIT BODIES
AND BOXES SPECIFICATION
|
| |
| ANSI
/ NEMA FB 1 - O.C. CONDULET CAST
IRON LIQUID - TIGHT IP 54 |
*
Standard
Materials : Cast Iron
*
Standard
Finish :
Hot - Dip galvanized |
|
|
|
|
Catalog
No.
|
Size
( in )
|
Dimensions
( mm. )
|
Weight
( Kg. )
Per 100
|
|
A
|
B
|
C
|
D
|
|
OCLT
HD050
|
1/2 "
|
121.75
|
34.75
|
34.80
|
98.00
|
32.30
|
|
OCLT HD075
|
3/4 "
|
140.45
|
40.75
|
42.00
|
118.70
|
50.90
|
|
OCLT
HD100
|
1 "
|
162.56
|
45.40
|
48.70
|
136.20
|
66.90
|
|
OCLT
HD125
|
1 1/4
"
|
191.68
|
59.50
|
61.70
|
164.44
|
116.30
|
|
OCLT
HD150
|
1 1/2
"
|
217.66
|
66.00
|
67.74
|
186.18
|
141.30
|
|
OCLT
HD200
|
2 "
|
261.90
|
77.75
|
87.20
|
241.00
|
235.60
|
|
| |
|
| |
| ANSI
/ NEMA FB 1 - O.T. CONDULET
CAST IRON LIQUID - TIGHT
IP 54 |
*
Standard
Materials : Cast Iron
*
Standard
Finish
: Hot - Dip
galvanized |
|
|
|
|
Catalog
No.
|
Size
( in )
|
Dimensions
( mm. )
|
Weight
( Kg. )
Per 100
|
|
A
|
B
|
C
|
D
|
E
|
|
OTLT
HD050
|
1/2
"
|
121.75
|
34.75
|
34.80
|
98.00
|
35.25
|
34.36
|
|
OTLT
HD075
|
3/4
"
|
140.45
|
40.75
|
42.00
|
118.70
|
38.88
|
55.80
|
|
OTLT
HD100
|
1 "
|
162.56
|
45.40
|
48.70
|
136.20
|
39.36
|
72.33
|
|
OTLT
HD125
|
1 1/4
"
|
191.68
|
59.50
|
61.70
|
164.44
|
51.70
|
127.80
|
|
OTLT
HD150
|
1 1/2
"
|
217.66
|
66.00
|
67.74
|
186.18
|
56.38
|
154.00
|
|
OTLT
HD200
|
2 "
|
261.90
|
77.75
|
87.20
|
241.00
|
65.64
|
258.00
|
|
OTLT
HD250
|
2 1/2
"
|
296.18
|
99.74
|
95.88
|
280.50
|
81.63
|
413.33
|
|
OTLT
HD300
|
3
|
317.86
|
112.60
|
110.80
|
306.30
|
85.20
|
568.33
|
|
OTLT
HD350
|
3 1/2
"
|
391.78
|
129.00
|
131.18
|
372.46
|
101.50
|
955.83
|
|
OTLT
HD400
|
4
|
391.78
|
138.86
|
144.18
|
371.16
|
112.97
|
1188.32
|
|
| |
|
|
| |
| ANSI
/ NEMA FB 1 - L.B. CONDULET
CAST IRON LIQUID - TIGHT
IP 54 |
*
Standard
Materials : Cast Iron
*
Standard
Finish
: Hot - Dip
galvanized |
|
|
|
|
Catalog
No.
|
Size
( in )
|
Dimensions
( mm. )
|
Weight
( Kg. )
Per 100
|
|
A
|
B
|
C
|
D
|
E
|
F
|
|
LBLT
HD050
|
1/2
"
|
110.50
|
35.00
|
35.30
|
98.20
|
34.70
|
90.70
|
31.20
|
|
LBLT
HD075
|
3/4
"
|
128.55
|
40.75
|
42.00
|
117.85
|
38.08
|
99.70
|
50.68
|
|
LBLT
HD100
|
1 "
|
151.12
|
45.50
|
48.00
|
135.75
|
41.48
|
123.05
|
69.75
|
|
LBLT
HD125
|
1 1/4
"
|
178.24
|
60.35
|
62.85
|
164.22
|
50.65
|
139.50
|
116.15
|
|
LBLT
HD150
|
1 1/2
"
|
201.18
|
65.95
|
66.00
|
185.40
|
58.48
|
163.68
|
140.80
|
|
LBLT
HD200
|
2 "
|
250.94
|
80.30
|
87.86
|
240.70
|
64.99
|
200.75
|
234.60
|
|
LBLT
HD250
|
2 1/2
"
|
286.14
|
100.26
|
95.00
|
279.50
|
80.02
|
226.00
|
375.40
|
|
LBLT
HD300
|
3
|
310.70
|
112.50
|
109.76
|
306.00
|
84.25
|
236.70
|
516.20
|
|
LBLT
HD350
|
3 1/2
"
|
382.12
|
129.00
|
131.18
|
371.16
|
101.50
|
304.80
|
868.00
|
|
LBLT
HD400
|
4
|
383.93
|
138.86
|
144.18
|
372.46
|
112.97
|
304.80
|
1079.30
|
|
| |
|
|
| |
| ANSI
/ NEMA FB 1 - L.L. CONDULET
CAST IRON LIQUID - TIGHT
IP 54 |
*
Standard
Materials : Cast Iron
*
Standard
Finish
: Hot - Dip
galvanized |
|
|
|
|
Catalog
No.
|
Size
( in )
|
Dimensions
( mm. )
|
Weight
( Kg. )
Per 100
|
|
A
|
B
|
C
|
D
|
E
|
F
|
|
LLLT
HD050
|
1/2
"
|
110.50
|
35.00
|
35.30
|
98.20
|
34.70
|
90.70
|
31.20
|
|
LLLT
HD075
|
3/4
"
|
128.55
|
40.75
|
42.00
|
117.85
|
38.08
|
99.70
|
50.68
|
|
LLLT
HD100
|
1 "
|
151.12
|
45.50
|
48.00
|
135.75
|
41.48
|
123.05
|
69.75
|
|
LLLT
HD125
|
1 1/4
"
|
178.24
|
60.35
|
62.85
|
164.22
|
50.65
|
139.50
|
116.15
|
|
LLLT
HD150
|
1 1/2
"
|
201.18
|
65.95
|
66.00
|
185.40
|
58.48
|
163.68
|
140.80
|
|
LLLT
HD200
|
2 "
|
250.94
|
80.30
|
87.86
|
240.70
|
64.99
|
200.75
|
234.60
|
|
LLLT
HD250
|
2 1/2
"
|
286.14
|
100.26
|
95.00
|
279.50
|
80.02
|
226.00
|
375.40
|
|
LLLT
HD300
|
3
|
310.70
|
112.50
|
109.76
|
306.00
|
84.25
|
236.70
|
516.20
|
|
LLLT
HD350
|
3 1/2
"
|
382.12
|
129.00
|
131.18
|
371.16
|
101.50
|
304.80
|
868.00
|
|
LLLT
HD400
|
4
|
383.93
|
138.86
|
144.18
|
372.46
|
112.97
|
304.80
|
1079.30
|
|
| |
|
|
| |
| ANSI
/ NEMA FB 1 - L.R. CONDULET
CAST IRON LIQUID - TIGHT
IP 54 |
*
Standard
Materials : Cast Iron
*
Standard
Finish
: Hot - Dip
galvanized |
|
|
|
|
Catalog
No.
|
Size
( in )
|
Dimensions
( mm. )
|
Weight
( Kg. )
Per 100
|
|
A
|
B
|
C
|
D
|
E
|
F
|
|
LRLT
HD050
|
1/2
"
|
110.50
|
35.00
|
35.30
|
98.20
|
34.70
|
90.70
|
31.20
|
|
LRLT
HD075
|
3/4
"
|
128.55
|
40.75
|
42.00
|
117.85
|
38.08
|
99.70
|
50.68
|
|
LRLT
HD100
|
1 "
|
151.12
|
45.50
|
48.00
|
135.75
|
41.48
|
123.05
|
69.75
|
|
LRLT
HD125
|
1 1/4
"
|
178.24
|
60.35
|
62.85
|
164.22
|
50.65
|
139.50
|
116.15
|
|
LRLT
HD150
|
1 1/2
"
|
201.18
|
65.95
|
66.00
|
185.40
|
58.48
|
163.68
|
140.80
|
|
LRLT
HD200
|
2 "
|
250.94
|
80.30
|
87.86
|
240.70
|
64.99
|
200.75
|
234.60
|
|
LRLT
HD250
|
2 1/2
"
|
286.14
|
100.26
|
95.00
|
279.50
|
80.02
|
226.00
|
375.40
|
|
LRLT
HD300
|
3
|
310.70
|
112.50
|
109.76
|
306.00
|
84.25
|
236.70
|
516.20
|
|
LRLT
HD350
|
3 1/2
"
|
382.12
|
129.00
|
131.18
|
371.16
|
101.50
|
304.80
|
868.00
|
|
LRLT
HD400
|
4
|
383.93
|
138.86
|
144.18
|
372.46
|
112.97
|
304.80
|
1079.30
|
|
| |
|
|
| |
| ANSI
/ NEMA FB 1 HOT - DIP BLANK
FOR L.B. , L.L. , L.R. ,
O.C. , O.T. , T.B. |
*
Standard
Materials : Cast Iron
*
Standard
Finish
: Hot - Dip
galvanized |
|
|
|
|
Catalog
No.
|
Hub
Size
|
Dimensions
( mm. )
|
O.D.Hole
( mm. )
|
Weight
Each
|
|
A
|
B
|
C
|
D
|
|
COVERHD050
|
1/2
"
|
34
|
97
|
84
|
4
|
5
|
95 g.
|
|
COVERHD075
|
3/4
"
|
40
|
119
|
104
|
4
|
5
|
140
g.
|
|
COVERHD100
|
1 "
|
45
|
135
|
124
|
4
|
6
|
190
g.
|
|
COVERHD125
|
1 -
1/4 "
|
57
|
163
|
153
|
4
|
6
|
289
g.
|
|
COVERHD150
|
1
- 1/2 "
|
64
|
186
|
164
|
4
|
6
|
350
g.
|
|
COVERHD200
|
2 "
|
77
|
240
|
216
|
4
|
7
|
520
g.
|
|
COVERHD250
|
2
- 1/2 "
|
95
|
276
|
259
|
4
|
7
|
985
g.
|
|
COVERHD300
|
3 "
|
108
|
303
|
287
|
5
|
8
|
1200
g.
|
|
COVERHD350
|
3
- 1/2 "
|
123
|
370
|
340
|
6
|
9
|
2000
g.
|
|
COVERHD400
|
4 "
|
130
|
374
|
351
|
6
|
9
|
2300
g.
|
|
| |
|
|
| |
| ANSI
/ NEMA FB 1 NEOPRENE GASKET
FOR L.B. , L.L. , L.R. ,
O.C. , O.T. , T.B. |
*
Standard
Materials : Cast Iron
*
Standard
Finish
: Hot - Dip
galvanized |
|
|
|
|
Catalog
No.
|
Hub
Size
|
Dimensions
( mm. )
|
O.D.Hole
( mm. )
|
Weight
Each
|
|
A
|
B
|
C
|
D
|
|
NEO050
|
1/2
"
|
34
|
97
|
84
|
2
|
5
|
13 g.
|
|
NEO075
|
3/4
"
|
40
|
119
|
104
|
2
|
5
|
15 g.
|
|
NEO100
|
1 "
|
45
|
135
|
124
|
2
|
6
|
22 g.
|
|
NEO125
|
1 -
1/4 "
|
57
|
163
|
153
|
2
|
6
|
31 g.
|
|
NEO150
|
1
- 1/2 "
|
64
|
186
|
164
|
2
|
6
|
37 g.
|
|
NEO200
|
2 "
|
77
|
240
|
216
|
2
|
7
|
60 g.
|
|
NEO250
|
2
- 1/2 "
|
95
|
276
|
259
|
3
|
7
|
105
g.
|
|
NEO300
|
3 "
|
108
|
303
|
287
|
3
|
8
|
125
g.
|
|
NEO350
|
3
- 1/2 "
|
123
|
370
|
340
|
3
|
9
|
180
g.
|
|
NEO400
|
4 "
|
130
|
374
|
351
|
3
|
9
|
195
g.
|
|
| |
|
|
|
|
|
|
