Chase Nipple and Threaded Close - up

  Certificated
Click View Detail

Click view detail

ABSO   CHASE NIPPLE   SPECIFICATION


ANSI / NEMA FB1 - CHASE NIPPLE
* Standard Materials : Cast Iron
* Standard Finish       : Hot Dip galvanized

Click View Detail
Catalog No.
Size ( in )
Dimensions ( mm. )
A
B
C
CA-HD050
1/2
15.50
11.15
24.35
CA-HD075
3/4
18.00
13.35
30.35
CA-HD100
1
23.55
16.25
37.00
CA-HD125
1 1/4
25.40
19.05
48.10
CA-HD150
1 1/2
26.10
22.22
52.20
CA-HD200
2
35.00
28.60
66.00
CA-HD250
2 1/2
37.00
30.16
78.40
CA-HD300
3
48.25
38.15
102.80
CA-HD350
3 1/2
48.75
37.80
114.10
CA-HD400
4
50.00
39.68
115.50
CA-HD500
5
64.00
51.50
153.75
CA-HD600
6
63.85
50.10
178.12




ABSO   THREADED CLOUSE - UP PLUGS   SPECIFICATION


THREADED CLOUSE - UP PLUGS
* Standard Materials : Cast Iron
* Standard Finish       : Hot Dip galvanized

Click View Detail
Catalog No.
Size ( in )
Dimensions ( mm. )
Weight ( Kg. )
Per Pc
A
B
C
PLG-HD050
1/2 "
18.00
14.00
29.00
55.00
PLG-HD075
3/4 "
22.00
14.00
33.00
100.00
PLG-HD100
1 "
22.00
14.00
36.00
140.00
